Hydro Pellet Stove - EDILKAMIN Vyda H18 / H22
Vyda H is the rigorously designed pellet heating stove, with a two-tone finish, which heats the whole house with hot water and it also produces hot air to heat the installation room (can be deactivated).
- Hearth in steel
• Rear smoke outlet
• Retractable display
• pellet reserve light : indicates that the product will still have autonomy for about half an hour from the time it appears on the display
• daily/weekly programming
• systems configurable from the display, with terminal board for external probes
• Front hot air ventilation (modular and deactivable)
• Leonardo system
• Expansion tank closed
OPTIONAL
• Wi-Fi kits
• GSM dialer
• Radio control kit with receiver
| Technical data | Vyda H 18 min/max |
Vyda H 22 min/max |
|
| length | cm | 62.5 | 62.5 |
| depth | cm | 61.5 | 61.5 |
| height | cm | 121.5 | 121.5 |
| useful power | kW | 4.9/18.7 | 4.9/22.5 |
| useful power to water | kW | 3.8/16.3 | 3.8/20 |
| yield | % | 93.3 | 92.7 |
| fuel consumption | kg/h | 1.1/4.2 | 1.1/5.1 |
| tank capacity | kg | 30 | 30 |
| autonomy | h | 7/27 | 6/27 |
| water content | L | 20 | 20 |
| Ø smoke outlet | cm | 8 | 8 |
| Ø air intake | cm | 5 | 5 |
| total weight | kg | 260 | 260 |
| vol. heatable (depending on the type of system) | m³ | 485 | 585 |
